YSF-1300 Laminator

Model：YSF-1300 1450 1650
Category：Automatic Laminator
Place of production:Guangdong, China
Product description:
INQUIRY

Product Display:

Product Features：

YSF series Automatic High-speed Laminating Machine boasts an automatic system for base-paper and laminating machine-layer feeding, suitable for high-speed automatic laminating process between color surface paper and the corrugated paper as the base. The machine consists of six parts: surface-paper feeder, surface-paper conveyor, base paper feeder, gluing roll, glue pasting & pressing roll and the conveyor for finished product, The surface-lamination is sent out from the feeder through the conveyor to the positing device. At the same time, the base paper goes out through the gluing roll, reaching this position as well. The two pieces are joined together and rolled out. Adopting PLC control system, the structure is simple and the control is stable and reliable; The working status is automatic display and fault status is automatic shutdown. By adopting the dual frequency controller to adjust the speed, the electric energy can be saved; No glue or papers, automatic alarm and shutdown.

Product Specification：

Model	YSF-1300	YSF-1450	YSF-1650
Max paper size(mm)	1300×1300	1450×1400	1650×1400
Min paper size(mm)	400×400	400×400	400×400
upper paper weight(㎡)	250-450	250-450	250-450
bottom paper type	A/B/C/D/E corrugated paper，thickness≦8mm
laminating accuracy	2-5mm adjustable(Former regulation accuracy：±1.5mm)
Machine speed(m/min)	laminating 72-164	laminating 72-164	laminating 72-164
Machine speed(m/min)	upper paper 10-32	upper paper 10-32	upper paper 10-38
Producing rate (pc/hour)	2000-6000	2000-6000	2000-6000
power (kw)	15	15	15
machine size(L×M×H)	13.90×2.22×2.68	14.10×2.41×2.68	15.62×2.61×2.68
machine weight(kg)	6800	7500	9000
